Heltecbms bms 48v 16s lifepo4/Lipo 16s 60v with balance 30a 50a 80a 100a 120a 160a 200a 250a 300a 350a board for inverter bms

Price range: $7 through $75

13 products sold in last 19 hours
Selling fast! Over 4 people have in their cart
22 people are viewing this right now
  • Check Mark Estimated Delivery : Up to 4 business days
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
16S 30A 50A 3.7V Same Port
Size: 72*55*8mm
Overcharge protection: 4.25v±0.25v
Charging recovery: 4.2V±0.25v
Over-discharge protection: 2.8v±0.25v
Discharge recovery: 3.0v±0.25v
Maximum continuous current: 30A/50A
Peak Current: 90A/150A
Balance current: 80 mA
Balanced starting voltage: 4.22v±0.25v
Charging recovery
Self-consumption: ≤35uA
16S 30A 50A 3.2V Same Port
Size: 72*55*8mm
Overcharge protection: 3.65v±0.25v
Charging recovery: 3.55V±0.25v
Over-discharge protection: 2.35v±0.25v
Discharge recovery: 2.55v±0.25v
Maximum continuous current: 30A/50A
Peak Current: 30A/150A
Balance current: 80 mA
Balanced starting voltage: 3.405v±0.25v
Charging recovery
Self-consumption: ≤35uA

16S 80A 120A 160A 3.7V Same Port
Size:115*66*8/12mm
Overcharge protection: 4.25v±0.25v
Charging recovery: 4.2V±0.25v
Over-discharge protection: 2.8v±0.25v
Discharge recovery: 3.0v±0.25v
Maximum continuous current: 80A/120A/160A
Peak Current: 240A/360A/480A
Balance current: 100 mA
Balanced starting voltage: 4.22v±0.25v
Charging recovery
Self-consumption: ≤35uA
16S 80A 120A 160A 3.2V Same Port
Size: 115×66×18
Overcharge protection voltage: 3.65V
Charge protection release voltage:3.55V
Over-discharge protection voltage: 2.35V
Discharge release voltage :2.55V
Balance start Volatge:3.4V
Abnormal high voltage protection: yes
Temperature protection: Optional
Maximal continuous current: 60A/80A/120/160A
Peak current :180A/240A/360A/480A
Balanced current:100Ma

16S 200A 350A 3.7V Same Port
Size: 190*97*14mm
Overcharge protection: 4.25v±0.25v
Charging recovery: 4.2V
Over-discharge protection: 2.8v±0.25v
Discharge recovery: 3.0v
Max continuous current: 160A
Max Charge Current :200A/350A
Peak Current: 600A/1050A
Balance current: 100 mA
Balanced starting voltage: 4.22v±0.25v
Charging recovery
16S 200A 350A 3.2V Same Port
Size: 190*97*14mm
Overcharge protection voltage: 3.65V
Charge protection release voltage:3.55V
Over-discharge protection voltage: 2.35V
Discharge release voltage :2.55V
Balance start Volatge:3.4V
Abnormal high voltage protection: yes
Temperature protection: Optional
Maximal continuous current: 200A/350A
Peak current :600A/1050A
Balanced current:100Ma

16S 250A 3.7V Same Port
Size: 150*80*14mm
Overcharge protection: 4.25v±0.25v
Charging recovery: 4.2V
Over-discharge protection: 2.8v±0.25v
Discharge recovery: 3.0v
Max continuous current:250A
Max Charge Current :750A
Peak Current: 240A/360A/480A
Balance current: 100 mA
Balanced starting voltage: 4.22v±0.25v
Charging recovery
16S 250A 3.2V Same Port
Size: 150*80*14mm
Overcharge protection voltage: 3.65V
Charge protection release voltage:3.55V
Over-discharge protection voltage: 2.35V
Discharge release voltage :2.55V
Balance start Volatge:3.4V
Abnormal high voltage protection: yes
Temperature protection: Optional
Maximal continuous current: 250A
Peak current :750A
Balanced current:100Ma

Sugget to conenct with Silicone cable with copper nose
Note: All holes need to be connect as pictures shows

Package include

color

16S 30A 3.7V Same, 16S 30A 3.2V Same, 16S 50A 3.7V Same, 16S 50A 3.2V Same, 16S 80A 3.7V Same, 16S 80A 3.2V Same, 16S 120A 3.7V Same, 16S 120A 3.2V Same, 16S 160A 3.7V Same, 16S 160A 3.2V Same, 16S 200A 3.7V Same, 16S 200A 3.2V Same, 16S 250A 3.7V Same, 16S 250A 3.2V Same, 16S 350A 3.7V Same, 16S 350A 3.2V Same, 8AWG Cable, 7AWG Cable Black, 7AWG Cable blue
